Janus is a self-manufactured vacuum chamber equipped with a Vacuum Thermal Evaporation (VTE) system. It was designed to investigate the formation and properties of organic thin films deposited through evaporation.

• MCh ID no.: 4.1_03
• Nickname: Janus
• Inventory number: (fill only if known)
• Person in charge: Héloïse Lasfargues, Sebastian Lellig

• Built: 2015
• Pressure:
  • without baking: -10^-7 mbar
  • with baking: N/A
• Watercooling for housing: none

• Evaporation source:
  • Electricly heated (R = 25 Ω) copper container which can be loaded with an aluminum crucible containing the precursor material.
• Pressure gauge: Leybold PENNINGVAC PTR 90
• Transformer: STATRON Type 5315 (250V AC/ 4.0 A)

Please write down a short MCh user manual or upload corresponding scans.

See current status and issues
