Mechanical Workshop
This page was machine translated to English from the German original, and its formatting slightly edited.
Zur deutschen Originalseite
Mechanical workshop is located in room EG_212.
Employees
Last updated: August 2024
- M. Momma, Head of Mechanical Workshop
- S. Dondorf, Mechanic
- T. Schneider, Mechanic
- L. Schimpfössl, Mechanic
- A. Yesilyurt, Apprentice
- N. Velten, Apprentice
- C. Belfqih, Apprentice
Tasks
- Mechanical processing
- Blasting of vacuum parts
- Ceramic processing and sample preparation
- Vacuum pump testing and maintenance
- Construction, conversion, systems - repair - installation and additions
- Drawings are created with CAD-SolidWorks
| Opening hours: | |
|---|---|
| Monday-Thursday | 07:30-15:45 |
| Friday | 07:30-15:00 |
For safety reasons, no one is allowed to work in the workshop outside of these times!
Machinery
Except for the SMG 50 (MGH) blasting machine, which should only be operated by trained employees, all other machines are only to be operated by workshop personnel!
- 1x TIG welding machine
- 1x MAG welding machine
- 1x Wood circular saw
- 3x Lathes
- 1x Milling machine
- 1x Coordinate drilling machine
- 1x Pillar drill
- 1x Bench drill
- 1x Band saw
- 1x Hacksaw
- 1x Metal circular saw
- 2x Bench grinders
- 1x Diamond drilling machine
- 1x Cutting machine
- 1x Water-cooled cutting machine
- 1x Spot welding machine (handheld device)
- 1x Spot welding machine mini
Instructions / User manuals
Blasting machine SMG 50
Strahlanlage
TIG/MAG welding machine Saturn 301:
Saturn 301
TIG welding machine Tetrix 230 AC/DC Comfort 5P TM:
Tetrix 230
Storage of the photo and video camera and its accessories
Video camera:
JVC GZ-E10SE
Photo camera:
Single-lens reflex Canon EOS 70D
Lenses:
Tamron 18-200mm 3,5-6,3 ; Canon Macro USM 100mm 1:2.8; Canon 50mm 1:1.8
Flash:
Canon Speedlite 430EX III-RT
Tripod:
Culmann Concept ONE 628
Remote control (infrared):
Canon RC-6
Remote control (cable):
Canon RS-60E3
Folding reflector:
Dörr 5-in1 80cm
